Manipulator3D — 3-DOF Two-Link Robot Arm (Analytic IK + Pick&Place)

A Ruby simulation and visualization project for a 3-DOF, two-link manipulator with a fixed base in 3D space. The arm executes a simple pick-and-place loop using an analytic inverse kinematics solver and a linear end-effector trajectory.

• Joint 0 (base): revolute yaw about the +Z axis at the origin (0,0,0).
• Joints 1–2 (links): revolute pitch angles defining motion in the arm’s vertical plane (relative to the X–Y plane).
• IK: reduces the 3D target to a 2D planar problem in (r,z), solves with the law of cosines, and supports elbow-up / elbow-down branches.
• Visualization: rendered with raylib via raylib-bindings, including an overlay panel and a suction-tool “ball” pick-and-place animation.

Language: Ruby • Rendering: raylib • Binding: raylib-bindings • IK: Closed-form

---

• About this repository
• Repository structure
• Robotics: kinematics, dynamics, and inverse kinematics
• Installing dependencies
• Running the simulator
• Repository file guide (full explanation)
• Simulation video
• Troubleshooting

---

About this repository

This project simulates a 3-DOF, two-link manipulator mounted on a fixed base at the origin:

• The base joint rotates around the Z axis (yaw).
• The two link joints rotate as pitch angles (relative to the X–Y plane) in the arm’s vertical plane.
• The end-effector (EE) tracks a sequence of target points with analytic inverse kinematics.
• A small “ball” is used to visualize a pick-and-place loop:
  1. HOME → START
  2. PICK at START (attach ball)
  3. START → GOAL
  4. PLACE at GOAL (detach ball)
  5. GOAL → HOME
  6. wait briefly and repeat

User inputs (via UI overlay):

• START position (x, y, z) and GOAL position (x, y, z) are entered in the on-screen panel.
• Press PAUSE to edit fields safely.
• Press PLAY (apply inputs) to validate and start a new loop with the new START/GOAL.
• Constraint enforced by IK: z must be ≥ 0
• Reachability enforced by IK: |p| must be within the arm’s reachable shell.

Font:

• The UI loads resources/fonts/Inter-Regular.ttf when present (recommended).

---

Repository structure

Manipulator3D_Ruby/
  Gemfile
  Gemfile.lock
  README.md
  resources/
    fonts/
      Inter-Regular.ttf
  src/
    main.rb
    raylib_bootstrap.rb
    util/
      math3d.rb
    robot/
      robot_arm.rb
    sim/
      trajectory.rb
    ui/
      overlay.rb
    render/
      draw_utils.rb

---

Robotics: kinematics, dynamics, and inverse kinematics

1) Coordinate frames and joint conventions

• World frame origin is at the center of the base revolute joint: (0,0,0).
• Joint angles:
  • q0_yaw : rotation about +Z (sets the arm’s radial direction in the X–Y plane)
  • q1_pitch: shoulder elevation angle relative to the X–Y plane
  • q2_pitch: elbow pitch angle (relative bend in the same vertical plane)

We use the radial unit direction in the X–Y plane:

$$\mathbf{u} = \begin{bmatrix} \cos(q_0)\\\ \sin(q_0)\\\ 0 \end{bmatrix}, \quad \mathbf{k} = \begin{bmatrix} 0\\\ 0\\\ 1 \end{bmatrix}.$$

2) Forward kinematics (FK)

Let link lengths be $L_1$ and $L_2$. Then:

• Elbow position:

$$\mathbf{p}_1 = L_1\cos(q_1)\,\mathbf{u} + L_1\sin(q_1)\,\mathbf{k}$$

• End-effector position:

$$\mathbf{p}_{ee} = \mathbf{p}_1 + L_2\cos(q_1+q_2)\,\mathbf{u} + L_2\sin(q_1+q_2)\,\mathbf{k}$$

Implemented in:

• Robot::RobotArm#forward_kinematics

3) Workspace (reachability) check

This manipulator is effectively a 2-link arm in a vertical plane, rotated by yaw. Therefore the reachable radius must satisfy:

$$r_{\min} = |L_1 - L_2|,\quad r_{\max} = L_1 + L_2$$ $$\|\mathbf{p}\| \in [r_{\min}, r_{\max}]$$

The implementation enforces:

• target.z >= 0
• |p| within [min_reach, max_reach]

4) Analytic inverse kinematics (IK): how it works here

Given target $\mathbf{p} = (x,y,z)$:

Step A — base yaw

$$q_0 = \mathrm{atan2}(y, x)$$

Step B — reduce to planar IK in $(r,z)$

$$r = \sqrt{x^2 + y^2}$$

Step C — elbow angle from law of cosines

$$\cos(q_2) = \frac{r^2 + z^2 - L_1^2 - L_2^2}{2L_1L_2}$$

Clamp to $[-1,1]$ for numerical safety, then:

$$q_2 = \pm \arccos(\cos(q_2))$$

Step D — shoulder angle

Define:

$$k_1 = L_1 + L_2\cos(q_2),\quad k_2 = L_2\sin(q_2)$$

Then:

$$q_1 = \mathrm{atan2}(z, r) - \mathrm{atan2}(k_2, k_1)$$

Implemented in:

• Robot::RobotArm#solve_ik

5) Dynamics (what is implemented vs. what is prepared)

This repository is primarily a kinematic + trajectory simulator:

• The EE follows a commanded Cartesian trajectory.
• IK converts EE targets into joint angles.
• FK is used for rendering joint/link positions.

The code also defines mass and inertia properties for each link (uniform rod approximations):

• About center of mass:

$$I_{cm} = \frac{1}{12} mL^2$$

• About the joint at one end:

$$I_{joint} = \frac{1}{3} mL^2$$

Computed in:

• Robot::LinkParams#recompute_inertia

These values are displayed in the overlay panel and can be used as a foundation for extending the simulator to include:

• forward dynamics (torques → accelerations),
• gravity and Coriolis terms,
• joint-space controllers (PD, computed torque, etc.).

---

Installing dependencies

Requirements

• Ruby (recommended: Ruby 3.x)
• Bundler (usually included with Ruby)

This project uses:

• raylib-bindings (raylib + helper libraries shipped as platform binaries)
• ffi (pulled automatically as a dependency)

Install

From the repository root:

bundle install

---

Running the simulator

From the repository root:

bundle exec ruby src/main.rb

Controls / interaction

• Mouse wheel: zoom camera
• F11: toggle fullscreen
• Overlay includes:
  • PAUSE / PLAY (apply inputs)
  • START/GOAL editable fields
  • reachability feedback

---

Repository file guide (full explanation)

This section explains every important file in the repository and its role.

Gemfile

Declares Ruby dependencies. The core dependency is raylib-bindings.

---

src/raylib_bootstrap.rb

Loads the raylib shared libraries shipped by raylib-bindings and enables direct calls to raylib functions (e.g., InitWindow, BeginDrawing, ...).

---

src/main.rb

Application entry point and runtime loop:

• initializes window + camera
• loads UI font (prefers resources/fonts/Inter-Regular.ttf)
• runs the pick-and-place finite-state machine:
  • HOME → START → PICK → GOAL → PLACE → HOME → WAIT → LOOP
• generates a linear Cartesian trajectory between targets
• runs IK each frame to get joint angles for the current EE target
• calls FK for rendering joint/link positions
• renders:
  • robot geometry, axes, ball, suction tool
  • overlay panel (inputs, status, pause/play)

---

src/util/math3d.rb

Small vector helpers and utility functions:

• vector constructors v2, v3
• add, sub, scale, length, normalize
• clamp, color_u8, rect

---

src/robot/robot_arm.rb

Robot model and kinematics API:

• LinkParams: link length, mass, inertia approximations (rod model)
• JointAngles: the 3 joint variables (yaw + 2 pitches)
• IKResult and FKResult
• RobotArm:
  • solve_ik
  • forward_kinematics
  • reach limits: min_reach, max_reach

---

src/sim/trajectory.rb

Minimal trajectory generator:

• Sim::LinearTrajectory:
  • reset(from,to,duration)
  • update(dt)
  • position
  • finished?

---

src/ui/overlay.rb

Overlay panel:

• editable START/GOAL input fields (when paused)
• PLAY applies inputs and starts a new loop
• shows:
  • link lengths, masses, inertias
  • workspace bounds
  • reachability and validation messages

---

src/render/draw_utils.rb

Rendering utilities using raylib primitives:

• draw_text_bold, draw_text_small
• robot visuals:
  • pedestal + base flange
  • joint housings (sphere + collar)
  • tapered link cylinders with end caps
  • suction tool at the EE

---

Simulation video

Below is a link to the simulation video on YouTube.

---

Troubleshooting

bundle install fails

• Make sure you are using a supported Ruby (3.x recommended).
• Update RubyGems and Bundler:

  gem update --system
  gem install bundler

The window does not open / crashes immediately on Windows

• Ensure your environment is 64-bit Ruby and you are using the x64-mingw gem build.
• If you have multiple Rubies installed, confirm:

  ruby -v
  which ruby

UI font looks wrong / fallback font is used

• Confirm the font exists:
  • resources/fonts/Inter-Regular.ttf
• If the file is missing or the font fails to load, the UI falls back to the default raylib font or a Windows font.

START/GOAL out of reach

• Ensure:
  • z >= 0
  • |p| is within [|L1 - L2|, L1 + L2]
• Use PAUSE to edit inputs, then PLAY to apply them.
